In-situ Raman High Temperature Reaction Cell

The in-situ Raman electrochemical cell is mainly used to study the Raman spectra of electrode materials in in-situ electrochemical experiments. The device is equipped with reference electrode and counter electrode, and reserved multi electrode and gas-liquid interface are reserved. At the same time, it can be used for various high temperature / ventilation atmosphere Raman.
Products Inquiry

Product Details

In-situ Raman High Temperature Reaction Cell


Product introduction

The in-situ Raman electrochemical cell is mainly used to study the Raman spectra of electrode materials in in-situ electrochemical experiments. The device is equipped with reference electrode and counter electrode, and reserved multi electrode and gas-liquid interface are reserved. At the same time, it can be used for various high temperature / ventilation atmosphere Raman.


Product parameters and characteristics

●Material of tank body: SUS316 + electroplating / injection molding;

●Window: quartz;

●Sealing ring: PTFE;

●Temperature test range: normal temperature ~ 600°C;

●Temperature control accuracy: ±0.1°C;

●Temperature uniformity: ±1°C;

●Surface temperature outside the cell: ≤ 40°C;

●Atmosphere: corrosive gases such as chlorinated gas and fluorinated gas can be connected.



●Material of tank body: 316L stainless steel;

●Window: quartz;

●Sealing ring: fluorine rubber ring;

●Temperature test range: normal temperature ~ 300°C;

●Temperature control accuracy: ± 0.1°C;

●Temperature uniformity: ± 1°C;

●Atmosphere: passable atmosphere;

●Light source: external light source can be introduced.
